CAD | CAM Design Services
CAD | CAM Design Services
by The Toolroom Ltd (TTR).
Bridging the gap between initial concept and precision manufacture with expert 3D modelling and CNC programming.
At The Toolroom Ltd (TTR), we believe that a high-quality finished component begins with a flawless digital foundation. Our integrated CAD (Computer-Aided Design) and CAM (Computer-Aided Manufacturing) services ensure that your designs are not only innovative but also optimised for efficient, cost-effective production.
Based in our North East toolroom, our design team works alongside our machinists to eliminate manufacturing errors before a single chip of metal is cut.
From Concept to Component: Our CAD/CAM Expertise
Whether you have a fully-realised 3D model or a rough hand-drawn sketch, we provide the technical expertise to bring your vision to life.
1. 3D Modelling & Product Development
Using industry-leading CAD software, we create high-fidelity 3D models for a variety of applications. We specialise in Design for Manufacture (DfM), identifying potential issues—such as draft angles, wall thicknesses, or tool access—early in the process to save you time and money.
2. Specialist Injection Mould Tool Design
With our deep roots in the toolmaking industry, we are experts in designing complex injection mould tools. Our CAD services include:
- Full 3D tool assembly design.
- Core and cavity extraction.
- Cooling circuit and runner system optimisation.
- Modification and repair mapping for existing tools.
3. Advanced CAM Programming
Our CAM department translates digital designs into high-efficiency toolpaths for our CNC Milling, Turning, and EDM machines. By utilising advanced strategies like high-speed trochoidal milling and 4-axis simultaneous paths, we achieve:
- Superior surface finishes.
- Reduced cycle times.
- Total dimensional accuracy to your digital master.
Our Software & Technical Capabilities
|
|
| CAD Software | Industry-standard 3D modelling and 2D drafting suites |
| File Formats | We accept and export: .STEP, .IGES, .DXF, .DWG, .STL, & more |
| Reverse Engineering | Re-creating CAD data from physical samples or worn components |
| Tooling Design | Comprehensive design of jigs, fixtures, and injection mould tools |
| Seamless Integration | Direct “CAD-to-Machine” data transfer for maximum precision |
Why Partner with Our Design Team?
Technical Feasibility First
We don’t just “draw parts.” As experienced toolmakers, we assess every design for its physical reality. If a design can be improved to reduce machining time or improve part strength, we will tell you. We stay true to our motto: “We do what we say we will do.”
Prototype to Production
Our CAD/CAM workflow is designed for agility. We can rapidly iterate 3D models for prototyping and then seamlessly scale the digital data for full-scale production tooling, ensuring total continuity of design.
Local Expertise, National Reach
Operating from the North East, we provide a collaborative design service. We act as an extension of your own engineering department, providing the specialist “toolroom perspective” that general design agencies lack.
CAD | CAM Design Services – Frequently Asked Questions
The Toolroom Ltd (TTR)
What CAD and CAM services does The Toolroom Ltd provide?
Which file formats do you accept for CNC machining and design?
Can you help with Design for Manufacture (DfM) to reduce costs?
Do you offer reverse engineering for broken or worn components?
We provide professional reverse engineering services, re-creating accurate CAD data from physical samples or worn components. This is ideal for digitising legacy parts or repairing broken components where original drawings are no longer available.
What is included in your injection mould tool design service?
Our specialist injection mould tool design is comprehensive, covering full 3D tool assembly, core and cavity extraction, and the optimisation of cooling circuits and runner systems. We also provide modification and repair mapping for existing tools to extend their production life.
How does your CAD/CAM workflow improve production quality?
By utilising advanced CAM strategies like high-speed trochoidal milling and 4-axis simultaneous paths, we achieve superior surface finishes and reduced cycle times. Our integrated workflow ensures total dimensional accuracy to your digital master, providing total continuity from prototype to full-scale production.
Ready to Digitise Your Next Project?
From reverse engineering a broken component to designing a multi-cavity injection mould tool, The Toolroom Ltd has the digital tools and the manual expertise to deliver.
Contact our design office today to discuss your CAD/CAM requirements.
